    20KW Roll To Roll Screen Printing Machine 3000 Meters Per Hour

    Roll-To-Roll Screen Printing Machine Suitable For Printing Various Consumables​


    Product Description

    1. Adopt the flat pressing round cylinder printing method, large- area printing is not sticky, and the printing thickness is thinner and the mate rialis not transparent.

    2. Multi-channel circulation heat preservation and drying mechanim , drying high efficiency and energy saving.

    3. The drying system adopts 360° intelligent circulation air drying. The ink on the material does not touch the transmission drum in the drying box, which does not affect the printing quality. The transmission drum in the oven does not need to be cleaned.

    4. When printing, it adopts the flat pressing and rounding process, and the material and the screen are separated synchronously, and there is no fear of large-color surface and full-page in printing.


    Use Power20kw
    Operating Voltage380V
    Heating Tube220v—-1.1kw
    Work Efficiency2500-4000 m/h
    Feeding Width1.25m
    Feeding Diameter1.1m
    Printing Area1100x1000mm
    Printable Non-Woven Fabric Thickness30-120g/㎡
    Weight4500kg
    Installation Size8x2.5x2.2(m)
    Packing Size7.2x2.5x2.2(m)/1.5x2.3x1.4(m)
    Basic OrganizationUnwinding + Printing + Drying + Brushing
    Random Accessories
    Hardware tool box*1Printing screen aluminum frame *1
    Small 24V relay *1Printing knives 3 sets of ink-returning knives (1 set for each of 0.6m, 0.9m and 1.2m)
    Proximity switch*2Printing tape*3 (1 set for each of 0.6m, 0.9m, 1.2m)
